Features
- High dust holding capacity;
- Large filter area;
- Large airflow and low pressure drop.
Applications
Apply to pre-filtration of various air-conditioning ventilation systems and dust removal systems.
- Technical Parameters
- Specifications
Description
Technical Parameters Not Available
Specifications
| Model | Size
(mm) |
CMH | I.N.P
(Pa) |
F.N.P
(Pa) |
Filter object
(μm) |
EFF.
(%) |
Filtration Class |
| RT-ZKC7725 | 595*595*25 | 1700/3400 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC5525 | 495*495*25 | 1200/2400 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC1725 | 295*595*25 | 850/1700 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC7746 | 595*595*46 | 1700/3400 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC5546 | 495*495*46 | 1200/2400 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC1746 | 295*595*46 | 850/1700 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC7796 | 595*595*96 | 1700/3400 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC5596 | 495*495*96 | 1200/2400 | <35/75 | <250 | ≥5 | 95% | G4 |
| RT-ZKC1796 | 295*595*96 | 850/1700 | <35/75 | <250 | ≥5 | 95% | G4 |
| Remark: customized specification is acceptable. | |||||||
