Features
- Large dust holding capacity and high filtration efficiency;
- High air flow and low resistance;
- Solid and beautiful structure.
Applications
Mainly used in the secondary or final filtration stage of various ventilation systems, air conditioning systems and dust removal systems with large air volume requirements.
- Technical Parameters
- Specifications
Description
Technical Parameters Not Available
Specifications
| Model | Size
(mm) |
CMH | I.N.P
(Pa) |
F.N.P
(Pa) |
Filter object
(μm) |
EFF.
(%) |
Filtration Class |
| RT-XSM7705-05 | 592*592*292 | 2200/4400 | <30/60 | <320 | ≥1 | 45% | F5 |
| RT-XSM1705-05 | 287*592*292 | 1100/2200 | <30/60 | <320 | ≥1 | 45% | F5 |
| RT-XSM7703-05 | 592*592*150 | 1800/3600 | <30/60 | <320 | ≥1 | 45% | F5 |
| RT-XSM1703-05 | 287*592*150 | 1000/1800 | <30/60 | <320 | ≥1 | 45% | F5 |
| RT-XSM7705-06 | 592*592*292 | 2200/4400 | <40/75 | <320 | ≥1 | 65% | F6 |
| RT-XSM1705-06 | 287*592*292 | 1100/2200 | <40/75 | <320 | ≥1 | 65% | F6 |
| RT-XSM7703-06 | 592*592*150 | 1800/3600 | <40/75 | <320 | ≥1 | 65% | F6 |
| RT-XSM1703-06 | 287*592*150 | 1000/1800 | <40/75 | <320 | ≥1 | 65% | F6 |
| RT-XSM7705-07 | 592*592*292 | 2200/4400 | <50/85 | <320 | ≥1 | 85% | F7 |
| RT-XSM1705-07 | 287*592*292 | 1100/2200 | <50/85 | <320 | ≥1 | 85% | F7 |
| RT-XSM7703-07 | 592*592*150 | 1800/3600 | <50/85 | <320 | ≥1 | 85% | F7 |
| RT-XSM1703-07 | 287*592*150 | 1000/1800 | <50/85 | <320 | ≥1 | 85% | F7 |
| RT-XSM7705-08 | 592*592*292 | 2200/4400 | <55/95 | <320 | ≥1 | 90% | F8 |
| RT-XSM1705-08 | 287*592*292 | 1100/2200 | <55/95 | <320 | ≥1 | 90% | F8 |
| RT-XSM7703-08 | 592*592*150 | 1800/3600 | <55/95 | <320 | ≥1 | 90% | F8 |
| RT-XSM1703-08 | 287*592*150 | 1000/1800 | <55/95 | <320 | ≥1 | 90% | F8 |
| RT-XSM7705-09 | 592*592*292 | 2200/4400 | <65/105 | <320 | ≥1 | 95% | F9 |
| RT-XSM1705-09 | 287*592*292 | 1100/2200 | <65/105 | <320 | ≥1 | 95% | F9 |
| RT-XSM7703-09 | 592*592*150 | 1800/3600 | <65/105 | <320 | ≥1 | 95% | F9 |
| RT-XSM1703-09 | 287*592*150 | 1000/1800 | <65/105 | <320 | ≥1 | 95% | F9 |
| Note: Other specifications can be customized according to demand. | |||||||
