Features
- High air-tightness;
- Low resistance;
- high filtration performance and dust holding capacity;
- Long service life;
- High material stiffness, no sagging of the bag;
- High airflow;
- low clogging rate;
- high strength of the filter bag;
- silicone free design;
- Compliance with EN 779-2012 testing standards;
- flame retardant in accordance with the German industrial standard DIN 53438 F1.
Applications
Mainly used in the secondary or back-end filtration of various ventilation systems, air conditioning systems and dust removal systems, and especially suitable for painting internal circulation systems.
- Technical Parameters
- Specifications
Description
Technical Parameters Not Available
Specifications
| Model | Size
(mm) |
Bags
(Pcs) |
CMH | I.N.P
(Pa) |
F.N.P
(Pa) |
Filter object
(μm) |
EFF.
(%) |
Filtration
Class |
Color |
| RT-DSHC7760-8P04 | 592*592*600 | 8 | 2200/3400 | <65/110 | <480 | ≥5 | 95% | G4 | white |
| RT-DSHC7760-6P04 | 592*592*600 | 6 | 2200/3400 | <70/120 | <480 | ≥5 | 95% | G4 | white |
| RT-DSHC5760-5P04 | 492*592*600 | 5 | 2000/3000 | <70/120 | <480 | ≥5 | 95% | G4 | white |
| RT-DSHC1760-3P04 | 287*592*600 | 3 | 1000/1500 | <70/120 | <480 | ≥5 | 95% | G4 | white |
| RT-DSHC7760-8P05 | 592*592*600 | 8 | 2200/3400 | <30/40 | <480 | ≥1 | 45% | F5 | white |
| RT-DSHC7760-6P05 | 592*592*600 | 6 | 2200/3400 | <35/45 | <480 | ≥1 | 45% | F5 | white |
| RT-DSHC5760-5P05 | 492*592*600 | 5 | 2000/3000 | <35/45 | <480 | ≥1 | 45% | F5 | white |
| RT-DSHC1760-3P05 | 287*592*600 | 3 | 1000/1500 | <35/45 | <480 | ≥1 | 45% | F5 | white |
| RT-DSHC7760-8P06 | 592*592*600 | 8 | 2200/3400 | <40/60 | <480 | ≥1 | 65% | F6 | white |
| RT-DSHC7760-6P06 | 592*592*600 | 6 | 2200/3400 | <50/65 | <480 | ≥1 | 65% | F6 | white |
| RT-DSHC5760-5P06 | 492*592*600 | 5 | 2000/3000 | <50/65 | <480 | ≥1 | 65% | F6 | white |
| RT-DSHC1760-3P06 | 287*592*600 | 3 | 1000/1500 | <50/65 | <480 | ≥1 | 65% | F6 | white |
| RT-DSHC7760-8P07 | 592*592*600 | 8 | 2200/3400 | <55/80 | <480 | ≥1 | 85% | F7 | white |
| RT-DSHC7760-6P07 | 592*592*600 | 6 | 2200/3400 | <60/85 | <480 | ≥1 | 85% | F7 | white |
| RT-DSHC5760-5P07 | 492*592*600 | 5 | 2000/3000 | <60/85 | <480 | ≥1 | 85% | F7 | white |
| RT-DSHC1760-3P07 | 287*592*600 | 3 | 1000/1500 | <60/85 | <480 | ≥1 | 85% | F7 | white |
| Note: Other specifications can be customized according to demand. | |||||||||
