Features
- High dust holding capacity and filtration efficiency;
- Large filtration area;
- Large airflow and low pressure drop.
Applications
Apply to primary or secondary filtration of various air-conditioning ventilation systems and dust removal systems.
- Technical Parameters
- Specifications
Description
Technical Parameters Not Available
Specifications
| Model | Size
(mm) |
CMH | I.N.P
(Pa) |
F.N.P
(Pa) |
Filter object
(μm) |
EFF.
(%) |
Filtration Class |
| RT-ZKM7746-05 | 595*595*46 | 1500/3000 | <30/55 | <250 | ≥1 | 45% | F5 |
| RT-ZKM5546-05 | 495*495*46 | 1000/2000 | <30/55 | <250 | ≥1 | 45% | F5 |
| RT-ZKM1746-05 | 295*595*46 | 750/1500 | <30/55 | <250 | ≥1 | 45% | F5 |
| RT-ZKM7746-06 | 595*595*46 | 1500/3000 | <40/70 | <250 | ≥1 | 65% | F6 |
| RT-ZKM5546-06 | 495*495*46 | 1000/2000 | <40/70 | <250 | ≥1 | 65% | F6 |
| RT-ZKM1746-06 | 295*595*46 | 750/1500 | <40/70 | <250 | ≥1 | 65% | F6 |
| RT-ZKM7746-07 | 595*595*46 | 1500/3000 | <50/80 | <250 | ≥1 | 85% | F7 |
| RT-ZKM5546-07 | 495*495*46 | 1000/2000 | <50/80 | <250 | ≥1 | 85% | F7 |
| RT-ZKM1746-07 | 295*595*46 | 750/1500 | <50/80 | <250 | ≥1 | 85% | F7 |
| RT-ZKM7746-08 | 595*595*46 | 1500/3000 | <55/90 | <250 | ≥1 | 90% | F8 |
| RT-ZKM5546-08 | 495*495*46 | 1000/2000 | <55/90 | <250 | ≥1 | 90% | F8 |
| RT-ZKM1746-08 | 295*595*46 | 750/1500 | <55/90 | <250 | ≥1 | 90% | F8 |
| RT-ZKM7746-09 | 595*595*46 | 1500/3000 | <60/95 | <250 | ≥1 | 95% | F9 |
| RT-ZKM5546-09 | 495*495*46 | 1000/2000 | <60/95 | <250 | ≥1 | 95% | F9 |
| RT-ZKM1746-09 | 295*595*46 | 750/1500 | <60/95 | <250 | ≥1 | 95% | F9 |
| Remark: customized specification is acceptable. | |||||||
